Description
Stinger Pro 185cc TWIN
UAV size engine
Stable and Powerful !
Ceramica coating cylinder head for longer use life
Parameter
| Type | 2 cycle piston valve type gasoline engine for airplane |
|---|---|
| Displacement (cc) | 185cc |
| Bore (mm) | 54 mm |
| Recommended props | 31×12 32×10 32×11 32×12 |
| Maximum Output | 22HP /7800rmp |
| Power supply | 7V-14V |
- Carburetor : Walbro
- Ignition : Stinger DC-CDI (Computer Controlled auto advance, electronic ignition system)
- SPARK PLUG: CM6
- Requires: Gasoline, 2-cycle oil, ignition battery & propeller
- speed rang : 1100-8000rpm
- Gasoline-Version : Pre-mixed Fuel, 40 (Gasoline):1 (recommended : 32:1 for real oil, or 40:1 for synthetic oil)
- Lubrication Oil : High quality fully synthetic 2 cylinder oil such as Motul 800 2T 100% synthetic racing motro oil , Red line two-stroke racing motor oil , Stihl Ultra high performance 2 cycle fully synthetic engine oil etc .
- Break in Propeller : 32×10 (Standard Two leafs prop)
- Cooling System : Air Cooled
- RCGF Stinger Engine package Includes: electronic CDI ignition, muffler, spark plug, gaskets, bolts, throttle arm extension & manual.
Weight:
- Engine: 3680 g
- 2XMuffler: 460 g
- Ignition Module: 190 g
Technical Data:
- Ignition Battery: 7V-14VNiCd or NiMH, 7V LiFe or 2S LiPo pack ( DO NOT use BEC, iBEC or uBEC)
- Gasoline/Oil Mix: (recommended : 32:1 for real oil, or 40:1 for synthetic oil)
- Replacement Spark Plug: CM6
- Idle Speed: 1100 rpm/min
